High Stability Multilayer Ceramic Capacitor Mid Voltage 2.2uF 450V

Shenzhen Winsun Technology Co., Ltd.
Contact Now

High Stability Multilayer Ceramic Capacitor Mid Voltage 2.2uF 450V

  • 1
  • 2

Brand Name : WS

Model Number : CKG57NX7T2W225MT009W

Certification : SGS

Place of Origin : China

MOQ : 1000pcs

Price : Lowest

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 1000000pcs/day

Delivery Time : 3-5 work days

Packaging Details : plastic reel + carton

Size : 2220

Capacitance : 2.2uF

Rated Voltage : 450v

Lead time : 3 days

Origin : Shenzhen of china

Payment : T/T; Western union; Paypal

Contact Now



High Stability Multilayer Ceramic Capacitor Mid Voltage CKG57NX7T2W225MT009W 2.2uF 450V





Features:
• High-accuracy automatic mounting is facilitated through the maintenance of very precise
  dimensional tolerances.
• Low residual inductance assures superior frequency characteristics.
• Low stray capacitance ensures high conformity with
  nominal values, thereby simplifying the circuit design process.
• Voltage rating of up to 630V
• High mechanical strength
• No polarity



* Size : 2220/ 5750
* Capacitance Range: 2.2UF
* Voltage range: 450V

* Capcitance Tolerance: +/-20%

* RoHS Compliant, Lead free





Applications:

• Output bypass in power supply
• Driver circuit in plasma display
• Noise bypass in automotive
• Other mid voltage applications etc...





Nominal Capacitance (pF):
The capacitance is expressed in three digit codes and in units of pico Farads(pF).

The first and second digits identify the first and second significant figures of
the capacitance. The third digit identifies the multiplier. R designates a decimal point.



Capacitance Code   Capacitance
           0R5                     0.5pF
           010                     1pF
          102                      1,000pF (1nF)
          105                      1,000,000pF (1μF)





Dimension Size:

Item Size(mm)
inch cm L W   Metal Terminal Width
2220 5750 6±0.50 5.00±0.50   1.60±0.30






High Stability Multilayer Ceramic Capacitor Mid Voltage 2.2uF 450V

High Stability Multilayer Ceramic Capacitor Mid Voltage 2.2uF 450V







Payment and Shipping:


1, Lead time about 3~5 days.
2, Payment: T/T; Western union; Paypal .
3, Shipping: by DHL, Fedex, TNT, UPS, EMS ect
